Details on
Gold anodes.

Anodes are made with two holes with a diameter (5±0.5)-(6±0.5) mm each, located at a distance of (9.0±2.0) mm from the upper edge and (11.0±2.0) mm from the lateral edges, counting from the centers of the holes.

At the request of the consumer, anodes are made without holes, with one or four holes.

Thickness, mm		Width, mm		Length, mm		Weight of one anode, g (reference)	Gold content, %, not less
Nomin. Sm.	Pre-off.	Nomin. Sm.	Pre-off.	Nomin. Sm.	Pre-off.	Weight of one anode, g (reference)	Gold content, %, not less
0,1	"-0,02	50	±5	100	±5	9,6	99,99
0,2	"-0,02	100	±5	200	±5	77,1
0,3	"-0,02	100	±5	200	±5	115,8
0,3		200	±5	300	±5	347,4
0,5		100	±5	200	±5	193,0
0,5		200	±5	300	±5	579,0
1,0		150	±5	300	±5	868,5
1,5		150	±5	300	±5	1302,8
2,0		150	±5	300	±5	1737,0
2,5		150	±5	300	±5	2171,3
3,0		150	±5	300	±5	2605,5
5,0		150	±5	300	±5	4342,5
